Common Mode Choke Core

Common Mode Choke Core

1.High permeability;

2.Reduce in size;

3.Reduce the winding turns;

4.Low DC resistance;

5.Low core loss;

6.High impedence overall the wide-range of frequency;

7.Meet the EN500081 and EN 500082 standards;

8.Getting a suitable insertion loss in wide-rang of frequency;

9.Low profile (1~5mm height). ​

Product Introduction

Common Mode Choke Core  ✉

The N80 series common-mode choke core is manufactured using high-permeability nanocrystalline alloy, specifically designed for EMI common-mode filtering and communication equipment, ensuring high impedance, low core loss, and stable performance.The product features a robust and reliable structure with a typical permeability of 80,000 and a low-profile height of 1-5mm. It complies with EN500081 and EN500082 standards.It is suitable for EMI filtering and telecom and data communication interface transformers. It is an ideal choice for nanocrystalline core applications in EMI suppression and power filtering.



Featuresproduct-800-800

  • High permeability
  • Reduced size
  • Reduced winding turns
  • Low DCR
  • Low core loss
  • High impedance across a wide frequency range
  • Compliant with EN500081 and EN500082 standards
  • Low-profile 1-5mm height





Applications

  • EMI common-mode filtering
  • Telecom and data communication interface transformers
  • High-precision current transformers
  • High-precision pulse transformers
  • Ground fault protection equipment
  • Switching power supplies
  • Frequency converters
  • UPS units



1





FAQ

Q: Does this product support customisation?

A: Yes. Parameters can be customised based on customer circuit diagrams or application requirements. Please contact our sales team to confirm the customisation plan.



Q: What is the typical lead time for mass orders?

A: Mass order lead time is generally 2-8 weeks. Custom products will be confirmed separately. The specific lead time is subject to confirmation at the time of order.



Q: Do you provide technical support and selection recommendations?

A: Yes. We have a professional technical team that can provide selection recommendations and customisation solutions based on customer application scenarios and circuit requirements.



SHINHOM is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in our Common Mode Choke Core ✉ products.

Hot Tags: common mode choke core, China common mode choke core manufacturers, suppliers, factory, Nanocrystalline Choke Core, Common Mode Choke Core, Amorphous Core, EMI Amorphous Beads, Nanocrystalline Cores, Amorphous Choke Cores
