Pulse transformer is a special kind of transformer that is specifically designed to handle pulse signals. It differs from a conventional transformer in terms of its design and structure, which are more complex as it needs to process signals of higher frequencies, not just DC or low-frequency signals.
Pulse transformers are typically made of two magnetic materials, one with low permeability and the other with high permeability. This design enables a magnetic field guiding effect, allowing pulse signals to move in a designated direction without spreading to other parts. Such a guiding effect is absent in conventional transformers.
Another difference from conventional transformers is that in pulse transformers, signals are not transmitted through wires wound around the iron core, but through the magnetic field inside the iron core. This design enhances the speed and efficiency of signal transmission while reducing signal distortion.
Pulse transformers can also enhance their performance through other means, such as adding isolation layers to prevent signal interference. Additionally, pulse transformers consume less energy than conventional transformers, as they can save significant electrical energy through magnetic fields.
In practical applications, pulse transformers are widely used in electronic devices such as communications, radar, measuring instruments, control systems, medical equipment, and industrial automation equipment. They are also utilized for amplifying, filtering, and adjusting signals, as well as providing power interfaces and isolation functions.
In general, the main differences between pulse transformers and conventional transformers lie in their design and structure. Pulse transformers have a more complex design that relies more on magnetic field effects to enable the processing of high-frequency pulse signals. They exhibit higher performance and efficiency, making them widely used in electronic devices
