PCB Mount Potential Voltage Transformers ✉
The Shinhom TV3XXX series of lamination, PCB Mounted voltage transformers are designed for applications where the primary AC voltage signal must be transformed accurately into a lower secondary AC voltage signal appropriate for micro-processor based circuit designs. These printed circuit board (PCB) mounted voltage transformers are designed to provide exceptional primary signal transformation accuracy with low phase shift while operating in harsh operating environments. The potential transformers (PT)/ voltage transformers (VT) feature high dielectric insulation and asymmetrical mounting packages.
| Product families | 1. VCT1062 ✉ | 2. VCT3452-670V 1.5V ✉ | 3. VT010-80 ✉ |
| 4. VT3452-670V-1.5V ✉ | 5. VTC1601-2mA-2mA ✉ |
FEATURES:
• standard sizes.
• Asymmetrical mounting pattern.
• Core lamination using Silicon steel or Nickel Alloy material.
• Printed circuit board mounted (PIH)
• Frequency: 50 to 400 Hz
•Secondary Output: Optional voltage from 0.10V to 7.07V @ Rated Current.
• Accuracy Class: as defined in IEC 60044-2 Part 2, Voltage Transformers.
• Isolation Voltage: 2500 Vac for 1 minute
• Dielectric Resistance: 1000 M Ohms @ 500 Vdc
• Surge Withstand: 5000V
• Operating Temperature: -25°C to +55ºC
Optional: -40°C to +85º C
• Construction: Exterior Material: ABS or PBT Resin
Interior Insulation: Epoxy resin encapsulated
SHINHOM is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in our PCB Mount Potential Voltage Transformers products.
