Rogowski Coil Current Sensor is a flexible current transducer based on Rogowski principle, particularly suitable for measurement in combination with portable devices. Our product are available in different sizes and can be supplied according to customer's design, therefore they can be used in all those applications, in which traditional transducers are not fitting due to its size and/or weight. Due to its specific features, flexible Rogowski coil is an extremely confortable solution for current measurement and can be used in a number of cases where traditional current transducer is not the adequate solution. Our Rogowski coil is provided with a shield against the influence of external magnetic fields, therefore it grants a stable measurement from low currents to hundreds of kA. The Rogowski coils must be connected to an electronic integrator for 90° phase shift compensation and frequency equalization. Our DIN-RAIL and panel meters can interface Rogowski coils directly without the need of the external integrators. This is an advantage because there is no external boxes or any power supply with consequent ease of use. The particular features of the Rogowski coils combined with the extremely flexible input programming of our portable meters, allow to carry out measurement by all applications.
FEATURE:
High linearity from 1A to 100kA
Wide dynamic range
Very useful with large size or awkward shaped conductors or in places with limited access
No danger from open-circuited secondary
Not damaged by large overloads
Non-intrusive, no power drawn from the main
Measurement uniformity at any position of the conductor inside the coil
Excellent degree of rejection to the external current conductor
APPLICATIONS:
Measuring devices, lab instrumentation
Power monitoring & control systems
DC ripple measurement
Harmonics and transients monitoring
Power meter,Power analyzer sensor
| Product families | 1. Flex Rogowski coil Y-FCT ✉ | 2. Flex Rogowski coil ZRC ✉ |
| 3. NRC Rogowski coil V2.0 ✉ | 4. MRC Rogowski coil V2.0 ✉ | |
| 5. Flex Rogowski coil SRC ✉ |
Shinhom is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in our Rogowski Coil Current Sensor products.
