Ferrite Absorber Plate ✉ ,are engineered to deliver broadband electromagnetic wave absorption from 30MHz to 1GHz. Widely used in EMC testing anechoic chambers and EMI shielding applications, they combine high strength, heat resistance, and non-flammability for reliable performance in high-power radiated immunity tests.
Technical Specifications
| Property | Value / Range |
| Absorption Frequency | 30 MHz – 1 GHz |
| Material | Ferrite (Mn-Zn / Ni-Zn based) |
| Flammability Rating | Non-flammable (UL 94 V-0 equivalent) |
| Mounting Method | Screw directly on shielding enclosure |
| Operating Temperature | -40°C to +105°C |
Models & Dimensions
Frequently Asked Questions
❓ How do I choose between the F Series sheets and the FBP Series blocks?
📐 The two product families are designed for different shielding scenarios:
- F Series Sheets are ideal for covering large interior surfaces of shielding enclosures and equipment cabinets.
- FBP Series Blocks are better suited for filling gaps, corners, seams, and localized leakage points.
For optimal EMI suppression, many engineers use both products together as part of a comprehensive shielding design.
❓ How are the absorbers installed? Is adhesive required?
🔩 No adhesive is required.
The absorbers can be mounted directly onto shielding enclosures or metal structures using mechanical fasteners such as screws. This installation method provides secure attachment while allowing convenient removal and replacement during maintenance or design modifications.
Get a Quote or Technical Advice
Tell us your required model, quantity, and application. We will reply within 24 hours.
📄 Download Full Datasheet (PDF) – Ferrite Absorber Plate
