AC Line EMI (Electromagnetic Interference) Filters are designed to suppress electromagnetic interference (EMI) on AC power lines, protecting electronic equipment from conducted noise while helping meet global EMC compliance requirements.
The product range covers both single-phase (120/250 VAC) and three-phase (250/440/480 VAC) power systems, with rated current options from 1 A to 1200 A. Various configurations are available, including PCB mount, chassis mount, IEC inlet filters, and shielded room power filters, providing flexible solutions for different applications.SHINHOM AC EMI filters are widely used in switching power supplies, office automation equipment, household appliances, medical equipment, industrial drives, UPS systems, automation equipment, and communication systems.
Features
- Wideband EMI Noise Suppression
- High EMI Filtering Performance
- Low Insertion Loss Design
- Low Leakage Current Option
- Wide Current Range: 1A–1200A
- Flexible Mounting Options Available
- Wide Operating Temperature Range
- RoHS Compliant Materials
Applications
- SMPS Input EMI Filtering
- Office Electronics & Equipment
- Consumer Appliance EMI Protection
- Medical Device Power Filtering
- Industrial Motor Drive Systems
- UPS Power Supply Systems
- Server & Network Equipment
- EMI-Controlled Shielded Environments
| Product families | 1. EMI Filter Catalog ✉ | 2. EMI filter ✉ | 3. EMI Power Line Filter ✉ | 4. LC2000 Filter ✉ |
FAQ
Q: What is the function of an AC Line EMI Filter?
A: An AC Line EMI Filter suppresses conducted electromagnetic interference on power lines. It prevents noise generated by electronic equipment from flowing back into the power grid and also blocks external disturbances from affecting equipment operation. It is a key component for achieving EMC compliance.
Q: How do I choose between single-phase and three-phase EMI filters?
A: Select the filter according to the power supply system.
Single-phase EMI filters are commonly used for household appliances, office equipment, and single-phase motors.
Three-phase EMI filters are designed for industrial equipment, frequency converters, motor drives, and high-power UPS systems.
Q: How should I select the rated current?
A: The filter's rated current should be higher than the maximum operating current of the equipment. A 20–30% safety margin is recommended for reliable operation.
For example:PE2100 series supports up to 100 A
PE3300/PE3400 series supports up to 1200 A
Q: Why is leakage current important?
A: Leakage current is the small current flowing from the filter to ground during normal operation. It is especially important in medical applications where strict safety limits apply (typically <0.5 mA). Low-leakage-current models, such as medical-grade versions, help meet healthcare equipment safety requirements.
Contact Us
SHINHOM – Your Trusted AC Line EMI Filter Manufacturer & Supplier
📧 Get a Quote | 📋 Request Free Samples | 📞 Inquiry Now
Please specify your required voltage, current rating, phase type, and mounting method. We will reply within 24 hours.
Tel: +86-29-85567686 / +86-29-87851838| Email: sales@shinhom.com.cn
SHINHOM is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in our AC Line EMI (Electromagnetic Interference) Filters ✉products.
