Ferrite Bead Inductor

SHINHOM is a Ferrite Bead Inductor Manufacturer and Supplier providing through-hole ferrite beads, SMD ferrite beads, and high-impedance ferrite beads for high-frequency EMI and RFI suppression in power and signal lines.

Different series are available for applications requiring EMI suppression, high current capability, low DC resistance, compact PCB installation, or high impedance at high frequencies. Custom ferrite bead inductors and OEM solutions are also available according to application and electrical requirements.

1.R6H Family

Through-hole Axial Ferrite Beads For EMI Suppression

FEATURES:

• Regged construction
• Counter measures for FCC,VDE
• CSA,CE,VCC1
• EMI/RFI suppression
• High reliability
• Long term stability

APPLICATIONS:

• Telecommunication Equipment
• Wireless Communications Equipment
• Computer Products
• General E;ectronic Applications where EMI/RFI suppression is required

Series in this family

2.RH Family

Through-hole Axial Ferrite Beads For EMI Suppression

FEATURES:

• Ferrite Core
• Regged construction
• Counter measures for FCC,VDE
• CSA,CE,VCC1
• EMI/RFI suppression
• Small size ,Low Cost
• Operating Temperature:-25℃ to +85℃
• Storage Temperature: -55℃ to +125℃

APPLICATIONS:

• Noise Filtering
• Amplifiers
• Switching Regulators
• Power Supplies
• Triac Control Circuits
• SCR Control Circuits

Series in this family

5.FB Family

FEATURES:

• Rugged construction
• Countermeasures for FCC, VDE
• CSA, CE, VCCI
• EMI/RFI suppression
• High reliability
• Long-term stability

APPLICATIONS:

• Telecommunication Equipment
• Wireless Communication Equipment
• Computer Products
• General Electronic Applications requiring EMI/RFI suppression

Series in this family

4.SMB4B Family

SMD Power Bead

FEATURES:

• Small size, high current, high performance.
• Low DCR, excellent EMI suppression capability.
• Suitable for surface mounting equipment.
• Operating temperature: -40℃ to 105℃

APPLCATIONS:

• VTR, digital set-top box, LCD Monitor
• DC/DC converters, xDSL
• Wireless communication equipment

Series in this family

5.SMB5H Family

SMD EMI Suppression 5-Hole Ferrite Bead

FEATURES:

• High Current rating
• Low DCR and high IDC beads inductor
• Compact and simple design with high reliability
• Very good SMD solution for traditional wide band choke
• Through-hole axial ferrite beads for EMI suppression
• Surface-mount wire wound beads with high frequency and EMI suppression

APPLCATIONS:

• Modems, PDP, LCD, and TVs converters
• Mobile radios, DC/DC converters
• Noise filtering devices
• Track and SCR control circuits
• Wireless communication equipments
• Computer disk drive and PC board to filter the EMI from outside sources such as car radios, mobile phones and VCRs

Series in this family

6.R8H-4TS Family

FEATURES:

• High Current Capacity
• Superior EMI Suppression
• Low DC Resistance
• Compact SMD Design
• Stable & Reliable

APPLICATIONS:

• Power supply lines in consumer electronics and industrial devices
• High-current data and signal lines in computing and communication systems
• Automotive electronics and control modules
• DC-DC converters and power management circuits
• EMI-sensitive instrumentation and measurement systems

Series in this family

How to Select a Ferrite Bead Inductor?

Selecting the right ferrite bead mainly depends on impedance, operating frequency, rated current, DC resistance, and mounting type.

1. Check the Impedance

Select an impedance suitable for the frequency of the unwanted noise. SHINHOM specifications provide impedance values at different frequencies for selected series.

2. Check the Rated Current

For power-line applications, choose a ferrite bead that can handle the required operating current without excessive temperature rise.

3. Check the DC Resistance

Low DC resistance helps reduce voltage drop and power loss, especially in high-current applications.

4. Select the Mounting Type

Through-Hole Ferrite Beads: suitable for leaded installation and applications requiring mechanical strength.

SMD Ferrite Beads: suitable for compact PCB layouts and automated assembly.

High-Impedance Ferrite Beads: suitable for stronger high-frequency noise suppression.

5. Match the Application

Consider the power or signal line, operating frequency, current, available space, and EMI requirements. For custom applications, the required electrical and mechanical specifications should be confirmed before selection.

Frequently Asked Questions

1. What is a ferrite bead inductor?

A ferrite bead inductor is a passive component used to suppress high-frequency EMI and RFI in power and signal lines.

2. What is a ferrite bead used for?

Ferrite beads are commonly used in power supplies, communication equipment, computers, DC/DC converters, automotive electronics, and other EMI-sensitive circuits.

3. How do I select the right ferrite bead?

The main parameters are impedance, frequency, rated current, DC resistance, mounting type, and size.

4. What is the difference between a through-hole and SMD ferrite bead?

Through-hole ferrite beads use leads and provide strong mechanical mounting, while SMD ferrite beads are designed for compact PCB layouts and automated assembly.

5. Can SHINHOM provide custom ferrite bead inductors?

Yes. SHINHOM provides custom ferrite bead inductors and OEM solutions according to electrical specifications, dimensions, mounting requirements, and application needs.
