CCFL Transformer,The series transformers is designed for use in cold cathode fluorescent lamp (CCFL) power supplies at operating frequencies up to 100 kHz. With output power from 3.5 to 14.0 Watts, these transformers are ideal for LCD backlight applications. They are available in two different gull wing, surface mount packages and one inboard configuration for height restricted designs.
Ambient temperature range: -40℃ to +85℃
Storage temperature range: Component: -40℃ to +85℃
Hi-Pot: Pri to Sec: 1500Vrms
Pri to Fb: 500Vrms
Winding to Core: 1500Vrms
| Product families | 1. CCFL ✉ | 2. STEPC13/STEM15 ✉ | 3. EFD25 ✉ |
SHINHOM is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in our CCFL Transformer products.
