PCB Mount Current Transformer are available in a variety of sizes and materials to meet any AC current sensing needs. Our universal design is made from the highest quality silicon steel core and meets the needs of most common AC current measurements.
FEATURES:
- 3750VDC insolation between winding to winding
- Frequency range: 10kHz to 1MHz
- Designed for use with switching power supplies meet UL/CSA/IEC 60950 Reinforced Insulation specification and provide 3 mm
- creepage/clearance between primary and secondary windings.
- Reinforced insulation per IEC 380
- Epoxy encapsulated construction
- Materials meet requirement of UL94V-0
| Product Series | Sec.Inductance(mH) | Sec.DCR(Ω) | |
| ACST-19XX | 8-5200 | 0.198-220 | ✉ |
| ACST014 | - | - | ✉ |
| ACST02 | 5-1260 | 0.6-21.5 | ✉ |
| ACST11 | 40-360 | 1.1-7.5 | ✉ |
| ACST19 | 5-80 | 0.65-4.5 | ✉ |
| ACST20 | 5-80 | 0.65-4.5 | ✉ |
| ACST2019 | 5-180 | 0.7-11.0 | ✉ |
| ACST00X | - | 0.7-11 | ✉ |
| ACST010-013 | - | 100 | ✉ |
| ACSTE20 | 5-2000 | 1-35 | ✉ |
| CT05 | 5-76 | 1.7 | ✉ |
| CT11XX | 4.7-1900 | 0.5-50 | ✉ |
| ZCT | 8.3-10.8 | - | ✉ |
| CT1312 | - | 88 | ✉ |
| CT2022 | - | 50-128 | ✉ |
| CT2520 | - | 24-92 | ✉ |
| ACST010F/FH | - | - | ✉ |
SHINHOM is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in our PCB Mount Current Transformer products.
