The PCB Mount Flyback Transformer is a type of transformer designed for flyback converter circuits. It is specifically used in applications that require voltage transformation, galvanic isolation, and energy storage.
The flyback transformer operates on the principle of energy storage in its magnetic core during the "on" time of the circuit, followed by releasing this stored energy during the "off" time. This allows for the generation of multiple output voltages or a single high-voltage output.
Key characteristics of PCB Mount Flyback Transformers include:
Energy Storage: Flyback transformers are designed to store energy in their magnetic cores during the "on" time of the switching cycle. This stored energy is then released during the "off" time to deliver the required voltage output.
Galvanic Isolation: Flyback transformers provide galvanic isolation between the input and output sides of the circuit. This isolation ensures safety and helps protect sensitive components from electrical noise and disturbances.
Voltage Conversion: These transformers can be designed to step up or step down the input voltage depending on the specific application requirements. They allow for efficient voltage conversion and regulation.
Compact and PCB Mountable: PCB mount flyback transformers are designed with compact dimensions and suitable mounting configurations for direct installation on a printed circuit board (PCB). They feature surface mount technology (SMT) for easy integration into the circuit design.
Customization Options: Manufacturers may offer customization options to meet specific application needs, such as different turns ratios, power ratings, and physical dimensions. Flyback transformers are commonly used in various power supply applications, including low-power DC-DC converters, LED drivers, battery chargers, and auxiliary power supplies.
SHINHOM is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in our PCB Mount Flyback Transformer products.
