SHINHOM is a professional manufacturer of NiZn Ferrite Core ✉ supplying high-performance magnetic materials composed primarily of NiO and ZnO.NiZn ferrite cores feature high electrical resistivity, low high-frequency core loss, high saturation flux density, and low coercivity, making them ideal for 1 MHz to 300 MHz high-frequency applications. They are widely used in RF inductors, intermediate frequency transformers, filtering coils, and chokes, providing a reliable magnetic core solution for high-frequency circuit design.Due to their excellent wideband characteristics, NiZn ferrite cores are also widely used for EMI and RFI suppression, making them a preferred choice for anti-interference magnetic components in RF and high-frequency electronic systems.
Features
- High resistivity – Up to 10⁸Ω·m, minimizes high-frequency losses
- Broadband frequency – Optimized for 1MHz–300MHz
- High saturation flux density – Bs up to 0.5T
- Low coercivity – Hc as low as 10A/m
- High Curie temperature – Superior thermal stability
- Porous structure – Reduces eddy current losses
- Low hysteresis loss – Enhances efficiency
- RoHS compliant – Environmentally friendly materials
Applications
- High-Frequency Inductors – 1 MHz–300 MHz RF chokes
- IF Transformers – RF signal transfer and conversion
- Filtering Coils – EMI/RFI noise suppression
- DC-DC Converters – High-frequency switching transformers
- RF Broadband Devices – Wideband energy transfer and impedance matching
- EMI Suppression – High-frequency anti-interference magnetic cores
FAQ
Q: What is the difference between NiZn ferrite and MnZn ferrite cores?
A: NiZn ferrite has significantly higher electrical resistivity (~10⁶ Ω·m vs MnZn ~10²–10³ Ω·m) and higher Curie temperature, resulting in much lower high-frequency losses. It is suitable for high-frequency applications above 1 MHz. MnZn ferrite offers higher permeability and is better suited for low-frequency (<1 MHz), high-power applications.
Q: What is the saturation flux density (Bs) of NiZn ferrite cores?
A: The saturation flux density reaches up to 0.5T, ensuring stable performance and reduced risk of saturation under higher current conditions.
Q: What are the advantages of NiZn ferrite cores in DC-DC converters?
A: NiZn ferrite enables higher switching frequencies, which significantly reduces transformer size and weight while improving power density in modern DC-DC converters.
Q: Why is electrical resistivity important for NiZn ferrite cores?
A: High resistivity (up to ~10⁶ Ω·m) minimizes eddy current losses, which is the key reason NiZn ferrite performs significantly better than MnZn ferrite at high frequencies.
Contact
SHINHOM – Your Trusted NiZn Ferrite Core Supplier
📧 Get a Quote | 📋 Request Free Samples | 📞 Inquiry Now
SHINHOM is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in our NiZn Ferrite Core products.
