A balun transformer (balanced-to-unbalanced transformer or impedance matching transformer) is a device used to convert signals between balanced and unbalanced circuits. It is commonly applied in telecommunications, audio/video equipment, RF circuits, and antenna systems.
The main function of a balun transformer is to match the impedance of source and load circuits while converting signal formats. This helps reduce signal loss, minimize common-mode noise, and improve overall signal integrity.
A typical balun consists of a magnetic core (such as ferrite) with multiple windings. The number and arrangement of windings depend on the application. For example, a 1:1 balun has one winding on each side, while a 1:4 balun has one primary winding and four secondary windings.
During operation, the balanced signal is applied to one side, and the other side provides an unbalanced signal (or vice versa). This conversion occurs through electromagnetic coupling between the windings and the core, ensuring proper signal transfer and impedance matching.
FEATURES:
- Supply high voltage and withstand voltage
- Operation frequency range from 40 to 80 KHz
- Deliver Output Power from 1.5 to 25 watts
- Slim or low profile Type easily built in your design
- Available in through-hole and SMT recess or gull wing type
APPLICATIONS:
- Applicable to light up cold cathodes fluorescent lamp of display.
- Such as DSC, PDA, Scanner, Car Navigation, Notebook PC, LCD monitor and LCD TV
SHINHOM is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in our SMD balun transformer products.
