Our SMD mount isolator frequency covers 80MHz~4GHz with small size, wide frequency band, stable performance, wide temperature range (-55~+125°C), high isolation, low loss, low standing wave, high intermodulation, large power and other characteristics have been widely used in power amplifier modules, system integration, radar, electronic countermeasures, aviation, navigation, etc. Medical equipment, intelligent identification of the Internet of Things, instruments, radio and television and other fields; Full range of products, short supply cycle, and according to customer special requirements can be customized.
Features：
● Wide Frequency Band
● Low Insertion Loss
● High Isolation
● Low VSWR
● High Power Handling
● Compact SMD Package
● Wide Operating Temperature Range
● RoHS Compliant
Applications：
● RF Power Amplifiers
● Wireless Communication Systems
● Radar Systems
● Electronic Warfare Equipment
● Aerospace & Navigation
● Satellite Communication
● RF Test & Measurement Equipment
● Broadcast Systems
● Medical Electronics
● IoT Wireless Devices
| Product families | Center Frequency(GHz) | Isolation(dB) | VSWR | Power(W) | |
| 110A | 0.806-2.593 | 22 | - | 80 | ✉ |
| G101D | 0.8765 | 22 | 1.13 | 130 | ✉ |
| G102B | 1.9875-2.593 | 17-23 | 1.17-1.33 | 20 | ✉ |
| G105B | 1.503-2.6 | 22-25 | 1.12-1.17 | 100 | ✉ |
| G105D | 0.771-2.66 | 23-28 | 1.12-1.19 | 150 | ✉ |
| HSI | 0.6-3.8 | 20-23 | 1.2-1.25 | 100 | ✉ |
| SG06 | 0.726-2.655 | 9-15 | 1.5-1.8 | 2 | ✉ |
SHINHOM is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in our SMD mount isolators products.
