Overview
A dual-channel rotary transformer combines two rotary transformers with different numbers of pole pairs, featuring two channels, each with two windings. The high-reliability rotary dual-channel rotary transformer offers 360-degree angle measurement with accuracy ranging from 20' to 15" selectable, multi-turn measurement, sensitivity, long life, resistance to high and low temperatures, vibration resistance, strong electromagnetic interference resistance, and multiple output interface options. It is an angle sensor with very stable output voltage.
Application
Due to its superior performance in angle and position measurement, dual-channel rotary transformers are widely used in fields requiring high-precision control such as aerospace, ships, weapons, and precision machinery. They are also widely applied in new energy fields such as wind power and solar energy.
Technical Data
|
Motor Model |
Number of Pole Pairs |
Excitation Frequency (Hz) |
Excitation Voltage (V) |
Output Voltage (V) |
Accuracy |
Zero Voltage (mV) |
Phase Shift (°) |
Weight (g) |
Temperature (°C) |
||||
|
Coarse |
Fine | Coarse | Fine |
Coarse(') |
Fine(") |
Coarse (') |
Fine (") | ||||||
|
J40XFS002 |
1 |
16 | 2000 | 4 | 2 | 2 | ≤20 | ≤±20 | ≤±40 | ≤±20 | ≤±40 | ≤100 | -55~+85 |
|
J50XFS002 |
1 |
16 | 2000 | 4 | 2 | 2 | ≤20 | ≤±20 | ≤±30 | ≤±20 | ≤±35 | ≤120 | -55~+85 |
|
J60XFS002 |
1 |
16 | 2000 | 4 | 2 | 2 | ≤20 | ≤±20 | ≤±25 | ≤±20 | ≤±30 | ≤180 | -55~+85 |
|
J65XFS002 |
1 |
16 | 2000 | 4 | 2 | 2 | ≤20 | ≤±20 | ≤±25 | ≤±20 | ≤±30 | ≤235 | -55~+85 |
|
J70XFS002 |
1 |
32 | 2000 | 4 | 2 | 2 | ≤25 | ≤±20 | ≤±25 | ≤±20 | ≤±30 | ≤260 | -55~+85 |
|
J75XFS002 |
1 |
32 | 2000 | 4 | 2 | 2 | ≤25 | ≤±20 | ≤±25 | ≤±20 | ≤±35 | ≤280 | -55~+85 |
|
J78XFS002 |
1 |
32 | 2000 | 4 | 2 | 2 | ≤25 | ≤±20 | ≤±20 | ≤±25 | ≤±40 | ≤320 | -55~+85 |
|
J80XFS002 |
1 |
32 | 2000 | 4 | 2 | 2 | ≤25 | ≤±20 | ≤±15 | ≤±20 | ≤±40 | ≤350 | -55~+85 |
|
J90XFS002 |
1 |
32 | 2000 | 4 | 2 | 2 | ≤25 | ≤±20 | ≤±15 | ≤±20 | ≤±30 | ≤400 | -55~+85 |
|
J100XFS002 |
1 |
32 | 2000 | 4 | 2 | 2 | ≤25 | ≤±20 | ≤±15 | ≤±20 | ≤±38 | ≤420 | -55~+85 |
|
J110XFS002 |
1 |
32 | 2000 | 4 | 2 | 2 | ≤25 | ≤±20 | ≤±15 | ≤±20 | ≤±40 | ≤500 | -55~+85 |
|
J120XFS002 |
1 |
32 | 2000 | 4 | 2 | 2 | ≤25 | ≤±15 | ≤±15 | ≤±10 | ≤±10 | ≤600 | -55~+85 |
|
J130XFS002 |
1 |
32 | 2000 | 4 | 2 | 2 | ≤25 | ≤±20 | ≤±15 | ≤±20 | ≤±38 | ≤700 | -55~+85 |
|
J150XFS002 |
1 |
32 | 2000 | 4 | 2 | 2 | ≤25 | ≤±20 | ≤±10 | ≤±20 | ≤±35 | ≤800 | -55~+85 |
SHINHOM is dedicated to setting a high bar of excellence for industries that integrate or utilize magnetics technologies in our Dual-Channel Rotary Transformer products.
